型號

Model

輸出

DC out

負載調整率

Load regul

紋波及噪聲

R﹠N

轉換效率

Efficiency

PSA50-220S5(C)

5v

10A

0.5%

80mV

78%

PSA50-220S12(C)

12v

4.2A

0.5%

120 mV

80%

PSA50-220S24(C)

24v

2.1A

0.5%

150 mV

81%

PSA50-220S36(C)

36v

1.4A

0.5%

150 mV

81%

輸入電壓范圍

AC input voltage range

220V±15%

輸入頻率

Input frequency

47～63Hz

浪涌電流

Inrush current

Cold start<30A/230VAC

輸入漏電流

Input leakage current

<1mA/230VAC

輸入電壓調節率

Line regulation(full load)

≤±0.5%

輸出電壓調節范圍

Output voltage adjust range

±5%

輸出過載保護

Output overload protection

105～150%,hiccup mode, auto recovery

絕緣耐壓

Withstand voltage

I/P—O/P  1.5KVac 1min

I/P—F/G  1.5KVac 1min

O/P—F/G  0.5KVac 1min

上升時間

Rise time

50ms@full load(typical)

保持時間

Hold up time

20ms@full load(typical)

工作溫度,濕度

Operating temperature ,Humidity

-10℃～+50℃,20～90%RH  無冷凝 (non condensing)

儲存溫度,濕度

Storage temperature ,Humidit

-30℃～+80℃ ,10～95%RH 無冷凝(non condensing)

安全標準

Safety standards

GB4943  EN60950

EMC標準

EMC standards

GB9254  EN55022

冷卻方式

Cooling method

convection
